TYPE	Series 220V	Series 400V	Series 500V	Series 690V
Max neutral w ire current	5KVar	10KVar15KVar/ 35KVar/50KVar/ 75KVar/100KVar	90KVar	120KVar
Nominal voltage	AC220V(-20%~+20%)	AC380V(-20%~+20%)	AC500V(-20%~+20%)	AC690V(-20%~+20%)
Rated frequency	50Hz±5%
Network	Single phase	Three-phase three-wire/three-phase four-wire
Response time	<10ms
Reactive power compensation rate	>95%
Machine efficiency	>97%
Switching frequency	32kHz	16kHz	12.8kHz	12.8kHz
Feature selection	Deal with harmonics/Deal with harmonics and reactive power	Deal with harmonics/Deal with harmonics and reactive power/ Deal with harmonics and three-phase unbalance /Three options
Numbers in parallel	No limitation. A single centralized monitoring module can be equipped with up to 8 power modules
Communication methods	Two-channel RS485 communication interface (support GPRS/WIFIwireless communication)
Altitude w ithout derating	<2000m
Temperature	-20~+50°C
Humidity
Pollution level	Below level Ⅲ
Protection function	Overload protection, hardware over-current protection, over-voltage protection, power grid voltage imbalance protection, power failure protection, over-temperature protection, frequency anomaly protection, short circuit protection, etc
Noise	<50dB	<60dB	<65dB
Installation	Rack/wall hanging		Rack
Into the way of line	Back entry (rack type), top entry (wall-mounted)		Top entry
Protection grade	IP20
