Wall Mount Installation 22kW AC Type-2 Output OCPP 1.6 Integrated EV Charger Point
Product Introduction
Wall Mount Installation 22kW AC Type-2 Output OCPP 1.6 Integrated EV Charger Point comes up with modern design for commercial and public charging. Embedded with RFID, Ethernet and LTE features makes it best suitable for mall and company charging applications. Compliant with OCPP 1.6J protocol enables it to be connected and operated with global EV charging management platform.
Specifications
| Housing material | Metal enclosure |
| Dimension (H x W x D) | 300 x 450 x 160 mm |
| Installation method | Wall mount |
| Cable routing | Bottom inlet |
| Net weight | 12.5kgs |
| Charging statndard | IEC 61851-22 Type-2 |
| Charging outlet | Cable output |
| Outlet number | 1 |
| Input voltage | 400V +/-10% 3-phase |
| Input frequency | 50Hz |
| Rated output power | 22kW |
| Measuring accuracy | Level 0.5 |
| Rated output voltage | 400V +/-10% 3-phase |
| Rated output current | 32A |
| Meter | MID certified |
| RCD | Type-B, sensitivity: 30mA |
| Network connection | Ethernet |
| User interface | RFID, LCD display |
Features
EV Charger Point Applications:
Company Overview
At Ark Tech, we want to establish a one-stop turnkey EV AC&DC Charger solutions that enable we are your first choice when it comes to implement EV AC&DC charger projects. The Ark Tech team has a great vision to provide you with stable and reliable DC charging solutions and services. With extensive experience and knowledge of electrical and digital power supply, we provide you with the most professional and practical project implementation guidance.
Our products are sold all over the world, you can rest assured.
